Client Portlands Energy Centre
Services Control Program & Monitoring
Location Toronto, Ontario
Posted On 02 May 2019

Challenge

To develop a control program for Escherichia coli (E. coli) that minimizes the potential impact of City of Toronto sanitary sewer overflows into the cooling water source that may be transferred inadvertently to the Outer Harbour, and potentially to the Cherry Beach area, during PEC operations.

Background

Portlands Energy Centre (PEC) was issued an Amended Certificate of Approval (C-of-A) for Industrial Sewage Works, to allow for the collection, transmission and disposal of once through non-contact cooling water and storm water drainage, by the Ontario Ministry of Environment. One of the conditions of the C-of-A, is a requirement for an E. coli Control Program. The Ontario Provincial Water Quality Objective (PWQO) is 100 E. coli colony forming units (CFU) per 100 mL, based on the geometric mean of a minimum of one sample per week from each of at least 5 sampling sites. When E. coli levels exceed the objective, the beach waters are posted as unsafe for swimming. The average Lake Ontario beach swimming season begins in early June and generally continues the first weekend in September.

Project

Data were collected over several years to characterize the relationship between E. coli concentrations within the cooling water source relative to precipitation and operational factors, as well as the influence of the cooling water effluent discharge upon the E. coli concentrations within the Outer Harbour and in particular the potential for influence at Cherry Beach. Monitoring included daily water quality sampling, evaluation of the effectiveness of hyperchlorination of the effluent during periods of elevated E. coli concentrations and modelling of the bacterial plume dispersion within the Outer Harbour, during the summer months.

Outcome

In consideration of the data collected since implementation, it is apparent that PEC’s E. coli Control Program is effective at minimizing the potential impact of City of Toronto sanitary sewer overflows into the Ship Channel, which may be transferred inadvertently to the Outer Harbour and potentially to the Cherry Beach area, during PEC operations.

The collection and analysis of the multi-year data, not only enabled the development of a control program that was proven effective at reducing E. coli concentrations in the cooling water effluent to levels protective of Cherry Beach, but was cost-effective for the client.

Robert Eakins, Senior Fisheries Ecologist at Ecometrix

Robert Eakins Associate, Senior Fisheries Ecologist
Brian Fraser Principal, Senior Aquatic Scientist
Carolyn Brown Environmental Scientist
Nichole Wiemann Environmental Scientist
